Compatibility |
Intel LGA1700/1200/2066/2011/1151/1150/1155/1156 AMD AM5/AM4 |
|
TDP |
220W |
|
Overall Dimension |
120×110×135mm (L×W×H) |
|
Heatsink Material |
7×?6mm Heatpipe+Copper Base+Aluminum Fin |
|
Weight |
760g (Heatsink+Fan) |
|
Fan Dimension |
120×120×25mm |
|
Fan Speed |
700±200~1800±10%RPM(PWM) |
|
Max. Air Flow |
76.16CFM |
|
Max. Static Pressure |
2.16mmH2O |
|
Noise |
15.2-35.2dB(A) |
|
Rated Voltage |
12VDC (4pin PWM) |
|
Operating Voltage |
10.8~13.2VDC |
|
Started Voltage |
7VDC |
|
Rated Current |
0.2A |
|
Power Input |
2.4W |
|
Bearing Type |
Hydraulic Bearing |
|
Connector |
4Pin PWM |
