Compatibility |
Intel LGA2066/2011/1700/1200/115X |
|
AMD AM5/AM4 |
|
|
TDP |
350W |
|
Radiator Dimension |
396×120×27mm |
|
Radiator Material |
Aluminum |
|
Tube Material |
Premium Sleeved Tubing |
|
Tube Length |
465mm |
|
Waterblock Dimension |
94x90x62mm |
|
Cold Plate Material |
Copper |
|
Pump Current |
0.32A MAX. |
|
Pump Speed |
0~2500RPM |
|
Pump Bearing |
Ceramic Bearing |
|
Pump Life Expectancy |
50,000 Hrs |
|
Pump Noise Level |
≤25dB(A) |
|
Rated Voltage |
12VDC |
|
Operating Voltage |
10.8~13.2VDC |
|
Started Voltage |
7VDC |
|
Power Input |
3W |
|
Connector |
4Pin PWM |
|
Fan on Radiator |
Fan on Pump |
|
|
Fan Dimension |
120×120×25mm |
70×70×15mm |
|
Fan Speed |
500±200~2000±10%RPM |
800~2800±10%RPM |
|
Max. Static Pressure |
2.68mmH2O |
1.92mmH2O |
|
Max. Air Flow |
78.25CFM |
23.0CFM |
|
Noise Level |
29.85dB(A) Max. |
28.0dB(A) Max. |
|
Current Input |
0.25A |
0.08A |
|
LED Lighting |
N/A |
5V ARGB |
|
Bearing |
Fluid Dynamic Bearing |
Ball Bearing |
