| Kamera | |
| Képérzékelő | 1/3” progressive Scan CMOS |
| Shutter Speed | 1/3 to 1/10000 s |
| Slow Shutter | Yes |
| aperture | 2.8 mm: F2.2 |
| 4 mm: F2.0 | |
| 6 mm: F2.0 | |
| Optika | 2.8 mm/ 4 mm/ 6 mm |
| Lens Mount | M12 |
| Min. szükséges megvilágítás | Color: 0.1 Lux; 0 Lux with IR |
| Day/Night Mechanism | IR Cut Filter |
| Day/Night Switch | Day/Night/auto/Schedule-Switch |
| Digital Noise Reduction | 3D DNR |
| WDR | DWDR |
| Weatherproof Rating | Ip67 |
| IR Working Distance | 30m |
| Látószög | 2.8mm: 88.2°/48.7°/106.5°(H/V/D) |
| 4mm: 74.6°/41.3°/88.1°(H/V/D) | |
| 6mm: 47.7°/26.5°/56°(H/V/D) | |
| LENS | |
| Type | Fixed Focal Lens |
| Focal Length | 2.8 mm/4 mm/6 mm |
| aperture | 2.8 mm: F2. 2 |
| 4 mm: F2.0 | |
| 6 mm: F2.0 | |
| FOV | 2.8 mm: |
| Horizontal FOV: 88.2°, Vertical FOV: 48.6°, Diagonal FOV: 106.5° | |
| 4 mm: | |
| Horizontal FOV: 74.6°, Vertical FOV: 41.3°, Diagonal FOV: 88.1° | |
| 6 mm: | |
| Horizontal FOV: 47.7°, Vertical FOV: 26.5°, Diagonal FOV: 56° | |
| Lens Mount | M12 |
| DORI Distance | 2.8 mm: |
| Detect: 45 m (149 ft) | |
| Observe:19 m (62 ft) | |
| Recognize: 9 m (30 ft) | |
| Identify: 5 m (15 ft) | |
