| Kamera | |
| Képérzékelő | 1/2.7” progressive Scan CMOS |
| Shutter Speed | 1/3 to 1/10000 s |
| Slow Shutter | Yes |
| Min. szükséges megvilágítás | 0.005 Lux; 0 Lux with IR/White light |
| Day/Night Mechanism | IR Cut Filter |
| Day/Night Switch | Unified/ Scheduled/ auto |
| LENS | |
| Type | Fixed Focal Lens |
| Focal Length | 2.8/4 mm |
| aperture | F1.6 |
| FOV | • 2.8 mm: |
| Horizontal FOV: 111.4°, Vertical FOV: 58.8°, Diagonal FOV: 134° | |
| • 4 mm: | |
| Horizontal FOV: 91.5°, Vertical FOV: 46.1°, Diagonal FOV: 109.6° | |
| Lens Mount | M12*p 0.5 |
| DORI Distance | • 2.8 mm |
| Detect: 85 m (278 ft) | |
| Observe: 35 m (116 ft) | |
| Recognize: 17 m (56 ft) | |
| Identify: 8 m (28 ft) | |
| • 4 mm | |
| Detect: 107 m (350 ft) | |
| Observe: 44 m (146 ft) | |
| Recognize: 21 m (70 ft) | |
| Identify: 11 m (35 ft) | |
| angle adjustment (Manual) | |
| Range | pan: 0° to 360°, Tilt: 0° to 90°, Rotation: 0° to 360° |
| ILLUMINaTOR | |
| IR LED | • Quantity: 2 |
| • Range: 30m | |
| • Wavelength: 850nm | |
| White LED | • Quantity: 2 |
| • Range: 30m | |
| Illuminator On/Off Control | auto/Scheduled/always on/always off |
| VIDEO | |
| Max. Resolution | 3840 X 2160 |
| Main Stream | • Frame Rate: |
| 50Hz: 1fps, 5fps, 10fps, 15fps, 20fps, 25fps | |
