| CaMERa | |
| Image Sensor | 1/2.8” progressive Scan CMOS |
| Shutter Speed | 1/3 to 1/10000 s |
| Slow Shutter | Yes |
| aperture | 2.8 mm: F2.2 |
| 4 mm: F2.0 | |
| Lens | 2.8 mm/ 4 mm |
| Lens Mount | M12 |
| Minimum Illumination | Color: 0.1 Lux; 0 Lux with IR |
| Day/Night Mechanism | IR Cut Filter |
| Day/Night Switch | Unified/ Scheduled/ auto |
| Digital Noise Reduction | 3D DNR |
| WDR | DWDR |
| Weatherproof Rating | Ip67 |
| IR Working Distance | 30m |
| Viewing angle | 2.8mm: 97.8°/52.9°/117.9°(H/V/D) |
| 4mm: 82.5°/44.9°/99.3°(H/V/D) | |
| LENS | |
| Type | Fixed Focal Lens |
| Focal Length | 2.8 mm/4 mm |
| aperture | 2.8 mm: F2.2 |
| 4 mm: F2.0 | |
| FOV | 2.8 mm: |
| Horizontal FOV: 97.8°, Vertical FOV: 52.9°, Diagonal FOV: 117.9° | |
| 4 mm: | |
| Horizontal FOV: 82.5°, Vertical FOV: 44.9°, Diagonal FOV: 99.3° | |
| Lens Mount | M12 |
| DORI Distance | 2.8 mm: |
| Detect: 49 m (161 ft) | |
| Observe: 20 m (67 ft) | |
| Recognize: 10 m (32 ft) | |
| Identify: 5 m (16 ft) | |
| 4 mm: | |
| Detect: 65 m (214 ft) | |
| Observe: 27 m (89 ft) | |
| Recognize: 13 m (43 ft) | |
| Identify: 7 m (21 ft) | |
