| Kamera | |
| Képérzékelő | 1/2.7” progressive Scan CMOS |
| Shutter Speed | 1/3 to 1/10000 s |
| Slow Shutter | Yes |
| Min. szükséges megvilágítás | 0.005 Lux; 0 Lux with IR/white light |
| Day/Night Mechanism | IR Cut Filter |
| Day/Night Switch | Day/Night/auto/Schedule-Switch |
| LENS | |
| Type | Fixed Focal Lens |
| Focal Length | 2.8/4 mm |
| aperture | 2.8 mm: F1.6 |
| 4 mm: F1.6 | |
| FOV | 2.8mm: |
| Horizontal FOV: 109°, Vertical FOV: 57°, Diagonal FOV: 128° | |
| 4mm: | |
| Horizontal FOV: 90°, Vertical FOV: 48°, Diagonal FOV: 107° | |
| Lens Mount | M12*p 0.5 |
| DORI Distance | 2.8 mm |
| Detect: 64 m (209 ft) | |
| Observe: 27 m (87 ft) | |
| Recognize: 13 m (42 ft) | |
| Identify: 6 m (21 ft) | |
| 4 mm | |
| Detect: 80 m (262 ft) | |
| Observe: 33 m (109 ft) | |
| Recognize: 16 m (52 ft) | |
| Identify: 8 m (26 ft) | |
| angle adjustment (Manual) | |
| Range | pan: 0° to 360°, Tilt: 0° to 85° |
| ILLUMINaTOR | |
| IR LED | Quantity: 1 |
| Range: 30m | |
| Wavelength: 850nm | |
| White LED | Quantity: 1 |
| Range: 30m | |
| Illuminator On/Off Control | auto/Scheduled/always on/always off |
| VIDEO | |
| Max. Resolution | 2880 X 1620 |
| Main Stream | Frame Rate: |
