| Kamera | |
| Képérzékelő | 1/3” progressive Scan CMOS |
| Shutter Speed | 1/3 to 1/10000 s |
| Slow Shutter | Yes |
| aperture | 2.8 mm: F1.6 |
| 4 mm: F1.6 | |
| Optika | Fixed focal lens (4 mm) |
| Lens Mount | M12 |
| Min. szükséges megvilágítás | 0 lux with IR/white Light |
| Day/Night Mechanism | IR Cut Filter |
| Day/Night Switch | Unified/ Scheduled/ auto |
| Digital Noise Reduction | 3D DNR |
| WDR | DWDR |
| IR Working Distance | 30m |
| Forgatási/döntési szög | pan: 0° to 360°, Tilt: 0° to 85°, Rotate: 0° to 360° |
| Illumination Distance | 30m |
| Látószög | (2.8 mm) Horizontal FOV: 102°, vertical FOV: 55°, diagonal FOV: 122° |
| (4 mm) Horizontal FOV: 79°, vertical FOV: 43°, diagonal FOV: 93° | |
| LENS | |
| Type | Fixed Focal Lens |
| Focal Length | 4 mm |
| aperture | F1.6 |
| FOV | Horizontal FOV: 80°, Vertical FOV: 43.2°, Diagonal FOV: 94.2° |
| Lens Mount | M12 |
| DORI Distance | Detect: 80 m (262 ft) |
| Observe: 33 m (109 ft) | |
| Recognize: 16 m (52 ft) | |
| Identify: 8 m (26 ft) | |
| angle adjustment (Manual) | |
| Range | pan: 0° to 360° |
| Tilt: 0° to 85° | |
| Rotate: 0° to 360° | |
| ILLUMINaTOR | |
| IR LED | Quantity: 2 |
