Smart Home Video Kapucsengő
|
SPECIFICATIONS |
||
|
Product Dimension |
149x47x30 mm |
|
|
Net Weight |
217g |
|
|
Power Cable Length |
1.5m |
|
|
Housing Material |
ABS+PC |
|
|
Housing Color |
White |
|
|
Housing Flame Retardance |
UL94 V-0 |
|
|
Ingress Protection(IP) |
IP65 |
|
|
Image Sensor |
1/2.8" 3MP CMOS |
|
|
Sensor Brand And Model |
SMARTSENS, SC301IOT |
|
|
Main Chipset Brand And Model |
INGENIC, T31ZL |
|
|
Lens Brand And Model |
HS-Q118 |
|
|
Lens Focal Length |
2.5mm |
|
|
Aperture |
F2.2 |
|
|
Power Supply |
DC 5V1.5A, AC 8~24V |
|
|
Working Power Consumption |
0.75W |
|
|
Standby Power Consumption |
1.3mW |
|
|
Live Stream Video Resolution |
FHD(1536*2048) / SD(432*576) |
|
|
Notification Image Resolution |
SD(432*576) |
|
|
Live Stream Effective Pixels |
3MP |
|
|
Optical pixel or lmage interpolation |
Hardware straight out |
|
|
Angle of View (H/V/D) |
100°(Horizontal) * 135°(Vertical) * 170°(Diagonal) |
|
|
Microphone Sensitive |
-38dB |
|
|
Noise Reduction |
3D NR |
|
|
Audio Input |
Built-in 38db Mic |
|
|
Audio Output |
Built-in 8ohms Speaker |
|
|
Audio Compression |
G711U |
|
|
Video Compression |
H.265 / H.264 |
|
|
Frame Rate |
IR CUT |
Support |
|
IR Distance |
5m |
|
|
Number Of Infrared Lamp Beads |
4pcs |
|
|
Night Vision Mode |
Black & White mode |
|
|
Wireless Standard |
Wi-Fi IEEE 802.11 b/g/n |
|
|
Wireless Frequency |
2412 MHz ~ 2472 MHz |
|
|
Wireless Encryption Protocol |
WEP/WPA-PSK/WPA2-PSK |
|
|
Working Temperature |
-20°C - +50°C |
|
|
Working Humidity |
10~95%RH (no condensation) |
|
|
|
